Cisco Catalyst 9200 Password Recovery (IOS XE)

We could not render this article right now.

Losing administrative access to a network switch is a critical but solvable situation. Cisco Catalyst 9200 switches provide a built-in recovery mechanism that allows administrators to reset or recover access without deleting the existing configuration, provided the correct procedure is followed.

This guide describes a clean, reliable, and production-safe method to recover access using console connectivity.

Requirements

To perform password recovery, you will need:

Physical access to the switch and its console port
For console access, we recommend using the CliDeck terminal, which provides a stable and convenient browser-based console experience for network devices.

Terminal session parameters:

Speed: 9600 baud

Data bits: 8

Parity: none

Stop bits: 1

Basic familiarity with Cisco CLI and ROMMON mode.

Recovery Workflow Overview

The password recovery process follows four logical stages:

Interrupting the normal boot process

Temporarily ignoring the startup configuration

Booting the system and restoring configuration manually

Setting a new password and returning to normal boot behavior

Step-by-Step Password Recovery (Standalone Switch)
Step 1: Power Cycle the Switch

Disconnect the power from the switch, then reconnect it to begin a fresh boot.

Step 2: Enter ROMMON Mode

During the early boot phase, interrupt the startup process:

Press Ctrl + C when prompted during boot

If no prompt appears, press and hold the Mode button until the following prompt is displayed:

switch:

Step 3: Ignore the Startup Configuration

At the ROMMON prompt, set the following variable:

switch: SWITCH_IGNORE_STARTUP_CFG=1


This instructs the system to bypass the startup configuration, including password enforcement.

Step 4: Boot the System

Start the normal boot process:

switch: boot


The switch will load the operating system without applying the saved configuration.

Step 5: Enter Privileged EXEC Mode

Once the system has booted:

Switch> enable


No password will be requested at this stage.

Step 6: Restore the Existing Configuration

If you want to keep the current configuration, load it into memory:

Switch# copy startup-config running-config


This restores the full configuration without enforcing the old password.

Step 7: Set a New Administrative Password

Create a new privileged user or update an existing one:

Switch(config)# username admin privilege 15 secret <new_password>


Use a strong password that complies with your security policy.

Step 8: Restore Normal Boot Behavior

Disable the configuration ignore mode:

Switch# no system ignore startupconfig switch all

Step 9: Save the Configuration

Persist all changes:

Switch# copy running-config startup-config

Optional: Completely Erase the Configuration

If your goal is to fully reset the switch and remove all previous configuration, use the following command instead of restoring the startup configuration:

Switch# write erase


This deletes the startup configuration entirely. After a reboot, the switch will start with factory-default settings.

Use this option only when configuration retention is not required.

Password Recovery in StackWise Deployments

For Catalyst 9200 switches operating in a stack:

Power off all members of the stack

Power on only the active switch

Perform the password recovery procedure

Power on the remaining stack members after completion

StackWise Virtual and Redundant Supervisor Systems

In advanced topologies:

Perform recovery only on the active device

Power off the standby unit during the process

Restore standby components after access has been recovered

Important Notes

This procedure allows password recovery without configuration loss when performed correctly

Always disable startup configuration ignore mode before saving

The write erase command permanently removes all configuration and should be used with caution

Conclusion

Cisco Catalyst 9200 switches offer a reliable and controlled mechanism for password recovery that minimizes operational risk. With physical access and proper console connectivity, administrative control can be restored quickly and safely.

Using the CliDeck terminal simplifies console access and makes recovery operations more predictable, especially when managing multiple devices or distributed environments.
