Junos Routing Engine Baselines: Keep Slots and Windows Separate

Short answer

Capture show chassis routing-engine before Junos maintenance and retain the slot identity and sampling window for each reported resource value. Compare like-for-like observations. A quiet Routing Engine does not certify packet forwarding, and a backup role alone does not establish that a switchover will succeed.

Scope and prerequisites

Juniper's command reference documents the generic command and platform-specific variants. It requires view privilege. Confirm the chassis family, Routing Engine model, installed Junos release and relevant member scope before adding selectors.

This is a resource baseline, not a failover or reboot procedure. Have the expected Routing Engine inventory and maintenance purpose available. If the operator cannot identify the inspected context, resolve that uncertainty before drawing conclusions from percentages.

1. Capture the full Routing Engine view

At the operational prompt, run:

show chassis routing-engine

Preserve each slot heading and its associated fields. Do not combine two Routing Engines into a single average. The currently active and backup contexts can have different workloads, so a difference is a question to investigate rather than proof of failure.

Record which expected engines appear. If the platform returns one engine, do not label that result as an inspection of a second engine that was not shown. Use exact platform help and the approved runbook to establish whether another context is needed.

Keep private hardware identifiers in the restricted capture location. A handoff can reference a private asset record without publishing its serial number.

2. Separate resource types and intervals

Read CPU, memory and temperature as separate observations. When the release reports several CPU windows, keep each window's label with its values. A short burst and a longer average can tell different stories about the same maintenance interval.

Preserve processor categories as printed instead of reducing every output to one unexplained busy percentage. Do not equate a load-average number with a CPU percentage. If a field is absent on the installed platform, record it as unavailable rather than filling it with an assumed zero.

Memory accounting can change between software families and releases. Juniper documents an inactive-memory accounting change for upgraded-FreeBSD platforms starting in Junos 15.1R1. Label a comparison across such a change instead of presenting the percentage difference as a hardware improvement.

Use the documented hardware limits and the organization's baseline when reviewing temperature. There is no universal temperature threshold in this runbook that certifies every Routing Engine model.

3. Make the comparison reproducible

Take another bounded capture at an agreed interval and record the workload or maintenance activity between captures. Compare the same engine, context, software and window. If the engine role changed, identify that change before comparing the numbers.

Include uptime or start information when printed so that a restart does not become an invisible break in the baseline. Retain an unknown reboot reason as unknown. It should not be rewritten into a convenient cause for an incident.

If one engine is unexpectedly missing or the resource view is incomplete, preserve the partial capture and escalate to the platform owner. Avoid performing a switchover as a diagnostic shortcut.

4. Define what remains unverified

Attach the resource baseline to a specific capture period and maintenance purpose. It does not establish forwarding capacity, routing convergence or configuration synchronization. Those outcomes need their own approved checks.

Use Junos alarm baselines for a separate alarm view, and Junos timing context when reconciling boot and protocol times. Keep each result's scope explicit in the handoff.

Verification note: acceptance criteria

For the actual chassis, Routing Engine models and Junos release, verify that the command completes, expected engines are accounted for, fields remain attached to slots and intervals, and comparison conditions are documented. Missing engines, unexplained role changes or incompatible memory accounting remain exceptions. These criteria describe an operator review; no physical test, measured capacity result or real device log is claimed.
